AC(交流)瓦特(50或60Hz,PF(功率因素)0.5到1.CT(比流器比值)=1) |
|
范圍
|
解析度
|
讀值準確度 (6800+6801)
|
讀值準確度 (6800+6802)
|
讀值準確度 (6800+3007)
|
|
5.0 – 99.9W
|
0.1W
|
±1% ± 0.8 w
|
±1% ± 0.8 w
|
±1% of Range
|
|
1.000 – 9.999 KW
|
0.001 KW
|
±1% ± 8 w
|
±1% ± 8 w
|
±1% of Range
|
|
10.00 – 99.99 KW
|
0.01 KW
|
±1% ± 8 0w
|
±1% ± 8 0w
|
±1% of Range
|
|
100.0 – 999.9 KW
|
0.1 KW
|
±1% ± 0.8kw
|
±1% ± 0.8kw
|
±1% of Range
|
|
1000 – 9999 KW
|
1 KW
|
±1% ± 8kw
|
±1% ± 8kw
|
±1% of Range
|
|
0.000 – 9.999MW
|
0.001MW
|
–
|
±1% ± 8 0kw
|
–
|
|
|
AC(交流)電流( 50 或 60Hz,自動檔位，真均方根值，波峰因素<4，CT=1) |
|
|
范圍
|
解析度
|
讀值準確度
|
|
6800+6801
(超載保護 AC200A)
|
0.050 – 9.999A
|
0.00A
|
±0.5% ± 0.05A
|
|
10.00 – 60.00A
|
0.01A
|
±0.5% ± 0.5A
|
|
60.00 – 99.99A
|
0.01A
|
±0.1% ± 0.5A
|
|
6800+6802
(超載保護 AC2000A)
|
0.04 – 10.00A
|
0.01A
|
–
|
|
0.4A – 100.0A
|
0.1A
|
±0.5% ± 0.5A
|
|
4.0 – 1000.0A
|
1A
|
±0.5% ± 5A
|
|
6800+ 3007
(超載保護 AC3500A)
|
4 – 300A
|
0.1A
|
±1% of Range
|
|
300.0 – 999.9A
|
0.1A
|
±1% of Range
|
|
1000 – 3000A
|
1A
|
±1% of Range
|
|
|
AC(交流)電壓 ( 50 或 60 Hz,自動檔位，真均方根值，波峰因素<4，輸入阻抗10M Ω ，VT(PT)=1CT=1，800V超載保護) |
|
范圍
|
解析度
|
讀值準確度
|
范圍
|
解析度
|
讀值準確度
|
|
4.0V – 500.0 (Phase to Neutral)
|
0.1V
|
± 0.5% ± 5dgts
|
4.0V – 600.0V (Phase to phase)
|
0.1V
|
± 0.5% ± 5dgts
|
|
|
AC(交流)電流的諧波分析(1~99階)6802大電流鉤部 |
|
范圍
|
百分比(%)
|
電流值(A)
|
|
解析度
|
讀值準確度
|
解析度
|
讀值準確度
|
|
1 – 20 th
|
0.1%
|
±2%
|
0.1 A
|
±2% of reading ± 0.4A
|
|
21 – 50 th
|
4% of reading ±2.0%
|
±4% of reading ±0.4A
|
|
51 – 99 th
|
6% of reading ±2.0%
|
±6% of reading ±0.4A
|
|
|
AC(交流)電流的諧波強度(1~99階)6801小電流鉤部，適合CT |
|
范圍
|
百分比(%)
|
電流值(A)
|
|
解析度
|
讀值準確度
|
解析度
|
讀值準確度
|
|
1 – 10 th
|
0.1%
|
±0.25 of reading ±1%
|
0.1mA / 0.1A
|
±0.2% of reading ±7dgts
|
|
11 – 20 th
|
±2% of reading ±1%
|
±2% of reading ±7dgts
|
|
2 1 – 50 th (A范圍)
|
±5% of reading ±1%
|
±5% of reading ±7dgts
|
|
2 1 – 50 th (mA范圍)
|
±10% of reading ±1%
|
±10% of reading ±7dgts
|
|
5 1 – 99 th
|
±35% of reading ±1%
|
±35% of reading ±7dgts
|
|
|
AC(交流)電流的諧波分析(1~99階)3007超大電流軟性鉤部 |
|
范圍
|
百分比(%)
|
電流值(A)
|
|
解析度
|
讀值準確度
|
解析度
|
讀值準確度
|
|
1 – 20 th
|
0.1%
|
±2%
|
0.1A / 1A
|
±0.2% of Range ±0.4A/40A
|
|
21 – 50 th
|
± 6%
|
±4% of Range ± 0.4A/40A
|
|
51 – 99 th
|
±10%
|
±6% of Range ± 0.4A/40A
|
|
|
范圍
|
解析度
|
讀值準確度 (6801)
|
讀值準確度 (6802)
|
讀值準確度 (3007)
|
|
0.0 – 20%
|
0.1%
|
±1%
|
±2%
|
±2%
|
|
20 – 100%
|
0.1%
|
±3% of reading ±5%
|
±6% of reading ±1%
|
±6% of reading ±1%
|
|
100 – 999.9%
|
0.1%
|
±10% of reading ±10%
|
±10% of reading ±1%
|
±10% of reading ±1%
|
|
|
交流電壓峰值(峰值>5V) 或 AC電流 (峰值>20A)，VT=1 |
|
范圍
|
取樣時間
|
讀值準確度
|
|
50Hz
|
19 μS
|
±5% ±30digits
|
|
60Hz
|
16 μS
|
±5% ±30 digits
|
|
|
諧波的波峰因素 (C.F.)(峰值>5V) 或 ACA(峰值範圍>10%)，VT=1 |
|
范圍
|
解析度
|
讀值準確度
|
|
1.00 – 99.99
|
0.01
|
±5% ±30digits
|
|
|
范圍
|
解析度
|
讀值準確度
|
|
45 – 65Hz
|
0.1Hz
|
0.2Hz
|
|
|
范圍
|
解析度
|
讀值準確度
|
|
0.00 – 1.00
|
0.01
|
± 0.04
|
|
|
范圍
|
解析度
|
讀值準確度
|
|
-180 。 to 180 。
|
0.1 。
|
± 1 。
|
|
