Agilent N5162A MXG ATE矢量信號發生器
名稱：信號發生器
品牌：
型號：
簡介：N5162A MXG ATE Vector Signal Generator 主要特性與技術指標 Signal Characteristics 100 kHz to 3 or 6 GHz +23 dBm up to 3 GHz using ...
- 產品介紹
N5162A MXG ATE Vector Signal Generator
主要特性與技術指標 Signal Characteristics
•100 kHz to 3 or 6 GHz
•>+23 dBm up to 3 GHz using a highly-reliable, fast-switching electronic attenuator
•W-CDMA dynamic range: typically ≤-73 dBc at +5 dBm output power
•≤900 μs simultaneous frequency, amplitude, and waveform switching in list mode
Modulation and Sweep
•AM, FM, øM, and pulse
•ASK, FSK,MSK, PSK, QAM
•Digital step and list sweep with simultaneous switching of frequency, power, and waveform
Baseband Generation and Signal Creation
•100 MHz internal I/Q baseband generator rate with real-time equalization for excellent EVM performance
•Up to 64 MSa playback memory and 800 MSa storage
•Create reference signals: LTE, HSPA+, WiMAX™, WLAN, DVB-H, DAB, MATLAB and more - Signal Creation
•Multi-channel Baseband generation, Digital I/O, MIMO Fading and RF to RF fading with N5106A PXB Baseband Generator and Channel Emulator
Automation and Communication Interface
•100BaseT LAN, LXI class-B, USB 2.0, and GPIB
•SCPI and IVI-COM drivers
•Backwards compatible with all ESG, PSG, 8648 signal generators, and other vendors´ signal generators
The last day to order is 31-May-2012. Orders must be booked by 31-May-2012.
Replacement Product:
•N5182A MXG RF Vector Signal Generator
For Highly Cost-Sensitive and Demanding ATE Production Environment
The N5162A MXG ATE RF signal generator provides the same industry-leading performance, reliability, and form factor (2RU) of the popular N5182A MXG -- all at a reduced price. This signal generator has been streamlined for automated test equipment (ATE) needs with the removal of the front-panel display and all connectors relocated to the rear panel for convenient and secure rack configurations. Combining the outstanding MXG performance with a base price reduction over the N5182A MXG signal generator, makes the N5162A MXG ATE vector signal generator ideally suited for today’s demanding production environment.
Maximize Uptime
Simplified self-maintenance decreases time for repair and performance verification, keeping downtime to less than 2 hours using field-replaceable assemblies.
